Trina 625W N-Type Bifacial Solar Panel
Specifications
- Brand: Trina Solar
- Model: Vertex N TSM-NEG19RC.20 625W
- Panel Type: N-Type Mono Bifacial (i-TOPCon)
- Power Output: 625 Watts
- Module Efficiency: \~23.1%
- Cell Technology: N-Type TOPCon, 210mm rectangular wafer design
- Glass Type: Dual Glass (tempered, front and rear)
- Bifacial Gain: Up to 20–30% (depending on installation surface)
- Weight: \~33 kg
- Frame Type: Anodized Aluminium Alloy
- Connector Type: MC4 Compatible
- Operating Temperature: -40°C to +85°C
- Mechanical Load: 5400 Pa (Front), 2400 Pa (Rear)
- Temperature Coefficients: Pmax -0.29%/°C, Voc -0.24%/°C, Isc +0.04%/°C
- Power Tolerance: 0 \~ +5W
- Warranty: 12 Years Product, 30 Years Linear Power Output
- Dimensions: 2382×1134×30 mm (93.78×44.65×1.18 inches)
Description
Trina 625W N-Type Bifacial Solar Panel – Ultra-High Power Module with i-TOPCon Technology
The Trina 625W N-Type Bifacial Solar Panel is engineered with advanced i-TOPCon cell technology, delivering high efficiency and excellent temperature performance. Its dual-glass bifacial design enables greater energy generation by capturing sunlight from both sides, ensuring maximum yield. Ideal for utility-scale, commercial, and industrial installations in Pakistan, it provides reliable performance, enhanced durability, and long-term energy output.
